Features
Small size, lightweight, easy to carry
The adoption of low-alloy structural steel plates, safer and longer service life
Grade 80 high strength load chain, high safety factor
Steady rotation, high efficiency, light hand pulling force
Approved by CE, GS Certificate
Double pawls, doube load chain guide wheel ensure the safe working
Overload protection required
Color: Red
Weight(KG): 15.000
CK-1T || Capacity - 1T | Standard Lift - 2.5m | Running Test - 1.5 | Effort required to lift max. load - 304N | No. of falls of load chain - 1 | Load chain diameter - 6mm | Dimensions - 126 x 147 x 302 x 36 mm | Net weight - 11.5kg
CK-1.5T || Capacity - 1.5T | Standard Lift - 2.5m | Running Test - 2.25 | Effort required to lift max. load - 343N | No. of falls of load chain - 1 | Load chain diameter - 6mm | Dimensions - 141 x 183 x 368 x 36 mm | Net weight - 17.5kg
CK-2T || Capacity - 2T | Standard Lift - 3m | Running Test - 3 | Effort required to lift max. load - 304N | No. of falls of load chain - 2 | Load chain diameter - 6mm | Dimensions - 141 x 183 x 368 x 36 mm | Net weight - 16kg
CK-3T || Capacity - 3T | Standard Lift - 3m | Running Test - 3 | Effort required to lift max. load - 343N | No. of falls of load chain - 2 | Load chain diameter - 8mm | Dimensions - 141 x 183 x 486 x 46 mm | Net weight - 27kg
CK-5T || Capacity - 5T | Standard Lift - 3m | Running Test - 7.5 | Effort required to lift max. load - 414N | No. of falls of load chain - 2 | Load chain diameter - 10mm | Dimensions - 163 x 215 x 616 x 46 mm | Net weight - 43kg
