Touch Start System – Smooth Arc-Striking with HF Control.
Rapid Arc Restrike – Quality narrow cutting and excellent travel speed.
Continuous adjustment of cutting current. Competitive Cutting Thickness(Carbon Steel) - Recommended thickness:10mm(External gas).
Automatic post-flow stop for rapid re-striking.
Cool Operation, Long Consumable Life –Cutting accessories with competitive price and performance.
Engine Drive Compatible – Wide range for input voltage,Select a suitable Engine Drive in remote locations.
Compact dimensions.
Auto-Protection against over-voltage, over-current and over-heated.
Energy Saving - Compared with the traditional cutting machine more efficient.
Color: Blue
Weight(KG): 9.000
Rated Input Voltage(V)：AC220 ±15% 1P
Efficiency(%)：80
Input Frequency (HZ)：50/60
Power Factor：0.73
Rated Input Power(KVA)：6.6
Protection Grade: IP21
Rated Input Current(A)：30
Arc-Initiating：H-F,Touch
Open Circuit Voltage(V)：230
Air Pressure(MPa)：0.4-0.5
Current Range(A)：20-40
Recommend Cutting Thickness（mm）：≤16
Rated Output Voltage（V）：96
Weight(kg)：9
Duty cycle at maximum current：60%@25℃
