Touch Start System (Untouch start modle optional)– Smooth Arc-Striking with HF Control.
Continuous adjustment of cutting current.
Rapid Arc Restrike – Quality narrow cutting and excellent travel speed.
Competitive Cutting Thickness(Carbon Steel) - Recommended thickness:15mm.
Automatic post-flow stop for rapid re-striking.
Cool Operation, Long Consumable Life –Cutting accessories with competitive price and performance.
Engine Drive Compatible – Wide range for input voltage,Select a suitable Engine Drive in remote locations.
Compact dimensions.
Auto-Protection against over-voltage, over-current and over-heated.
Color: Blue
Weight(KG): 19.000
Energy Saving - Compared with the traditional cutting machine more efficient.
Rated Input Voltage(V)：AC220V±15% 1P
Efficiency(%)：80
Input Frequency (HZ)：50/60
Power Factor：0.73
Rated Input Power(KVA)：9.9
Protection Grade：IP21
Rated Input Current(A)：45
Arc-Initiating：H-F,Touch
Open Circuit Voltage(V)：240
Air Pressure(MPa)：0.4-0.5
Current Range(A)：20-60
Recommend Cutting Thickness（mm）：≤20
Rated Output Voltage（V）：104
Weight(kg)：19
Duty cycle at maximum current：60%@25℃
Dimension(mm)：480*203* 375
